Brand Name : | HQPA/OEM |
Model Number : | Swing Motor HZZC-M2X170CHB 31Q8-10130 |
Certification : | ISO9001 |
Price : | negotiation |
Payment Terms : | Western Union, L/C, T/T, MoneyGram, D/A, D/P |
Supply Ability : | 500 PCS per Month |
Delivery Time : | 3-5 days after payment received(public holiday excluded) |
Product Description
Part Name | Swing Motor HZZC-M2X170CHB 31Q8-10130 for R290-7 R300-7 R305-7 R335-7 |
Position | Track Frame/Swing Motor |
Material | Stainless Steel |
OEM | HZZC-M2X170CHB 31Q8-10130 |
Type | Swing Motor |
Application | Hyundai R290-3 R290-5 R290-7 R300-5 R300-7 R305-7 R305-9 R335-7 R335-9 |
Color | HQPA/OEM |
Feature | Standard size |
Product Category | Hydraulic Parts |
Packing Method | PP bag inside, carton box outside |
Delivery Time | 3-5 days after payment received(public holiday excluded) |
The Port of Loading | HUAGNPU,China (Mainland) |
Transport Method | AIR / SEA / EXPRESS |
Payment Terms | Western Union, L/C, T/T, MoneyGram, D/A, D/P |
Refereence. | Part No | Parts name |
*. | 31Q8-10150 | SWING MOTOR ASSY |
*. | 31Q8-10151 | SWING MOTOR ASSY |
*-1. | 31Q8-10130 | SWING MOTOR UNIT |
101 | XKAH-01090 | SHAFT-DRIVE |
111 | XKAH-00160 | BLOCK-CYLINDER |
113 | XKAH-00159 | BUSHING-SPHERICAL |
113 | XKAH-01621 | BUSHING-SPHERICAL |
114 | XKAH-00158 | SPRING |
114 | XKAH-01484 | SPRING |
116 | XKAH-01079 | ROD-PUSH |
121 | XKAH-01162 | PISTON ASSY |
123 | XKAH-01081 | RETAINER |
124 | XKAH-00151 | PLATE-SHOE |
131 | XKAH-01082 | PLATE-VALVE |
131 | XKAH-01161 | PLATE-VALVE K1 |
301 | XKAH-01091 | CASING |
303 | XKAH-01084 | CASING-VALVE,R |
304 | XKAH-00930 | COVER-FRONT |
351 | XKAH-01085 | PLUNGER |
443 | XKAH-00139 | BEARING-ROLLER |
444 | XKAH-00138 | BEARING-ROLLER |
451 | XKAH-00137 | PIN-SPRING |
464 | XKAH-01157 | PLUG ASSY-VP |
469 | XKAH-01237 | PLUG ASSY-VP |
702 | XKAH-00130 | PISTON-BRAKE |
742 | XKAH-00126 | PLATE-FRICTION |
743 | XKAH-00125 | PLATE-SEPERATION |
51 | XKAH-01086 | RELIEF VALVE |
31 | XKAH-01268 | BRAKE VALVE |
747 | XKAH-01094 | PLATE-NAME |
747 | XKAH-01624 | PLATE-NAME |
The following seal kits we also can supply: Main pump seal kit; Hydraulic pump seal kit; Regulater valve seal kit; Plunger pump seal kit; O ring box; Gear pump seal repair kit, Travel motor seal kit, Breaker hammer seal kit; Swing motor seal kit, Lever seal kit; Pilot valve seal kit/PPC seal; Adjuster seal kit; Center joint seal kit; Turing joint seal kit; Servo valve seal kit; Boom cylinder seal kit; Arm cylinder seal kit; Bucket cylinder seal kit; Control valve seal kit. About Our Services · Wide product range and delivery goods in time · Choosing the best quality of products (if we don't make) for customers in whole China. · Guaranteed quality and pretty competitive price. · Products are superior in quality. Each product must pass strict inspection by our QC and engineer. · Accept orders for products custom-made according to your drawings or technical specification. |
