    2438U568R100 Piston Rod Seal Repair Kit For Kobelco K909-A K909A

    Ask Lasest Price
    Brand Name : HQPA/OEM
    Model Number : 2438U568R100 Piston Rod Seal Repair Kit
    Certification : ISO9001
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T, MoneyGram, D/A, D/P
    Supply Ability : 500 Sets per Week
    Delivery Time : 3-5 days after payment received(public holiday excluded)
    • Product Details
    • Company Profile

    2438U568R100 Piston Rod Seal Repair Kit For Kobelco K909-A K909A

    2438U568R100 Piston Rod Seal Repair Kit for Kobelco K909-A K909A

    1.Product Description:


    Hydraulic cylinder seal kits are used to seal the gap between different parts of the hydraulic cylinder. The function of hydraulic cylinder seal kits is to prevent oil leakage, to assure the working pressure of the hydraulic system, to maintain its power.



    2.General Product Information:


    2438U568R100 Piston Rod Seal Repair Kit for Kobelco K909-A K909A
    Brand NameHQPA/OEM
    Product Name2438U568R100 Piston Rod Seal Repair Kit for Kobelco K909-A K909A
    Product stylePiston Rod Seal Repair Kit / Rod Seal Repair Kit
    Part No.2438U568R100 2438U568R110 2438U568R120
    Related parts:Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit
    ApplicationKobelco K909-A K909A K907 K907LC K909LC
    MOQ1 PC
    Condition100% New
    PackageInner-Plastic Bag; Outer -Standard Carton Box.
    PaymentWestern Union, L/C, T/T, MoneyGram, D/A, D/P etc.
    Departure portsHuangpu(Guangzhou), China (Mainland)
    Delivery time3-5 days after payment received(public holiday excluded)
    Place of originChina (Mainland)
    ApplicationExcavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck.

    3. Fit Model


    Part Number: 2438U568R100
    Group: Piston Rod Seal Repair Kit
    Fit for model: Kobelco K909-A K909A K907 K907LC K909LC


    4.Related parts


    2438U568R100 Piston Rod Seal Repair Kit for Kobelco K909-A K909A


    Part NoParts namePart NoParts name
    2438U568F5CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS2438U568F6CYLINDER
    2438U568F10CYLINDER ASSY, BUCKET, CONSISTS OF THE FOLLOWING PARTS2438U568S2BUSHING
    2438U568S3RODR45P0049D3SEAL
    R45P0051D5O-RINGR45T0014D4WEAR RING
    ZD12G06000O-RING,59.40mm ID x 65.60mm OD x 3.10mm2438U568S9BACK-UP RING
    2438U308S44NUT2438U308S45LOCKING RING
    2438U568S14COVER2438U308S15BUSHING
    2438U308S16CLIPZD12P12000O-RING
    2438U308S18BACK-UP RING2438U308S39O-RING
    R45P0050D10SEALR45P0050D21O-RING
    2438U322S33PACKING2438U568S25BUSHING
    2438U282S23SNAP RINGZS23C14055SCREW,Hex Socket Head, M14 x 55mm
    2438U568S28TUBE, CYLINDER2438U568S29ROD
    2445R138D6SEAL,70mm ID x 85.3mm OD x 4mm Thk2445R138D7SEAL,80mm ID x 95mm OD x 4mm Thk
    2438U568S32SPRING F10 ONLY2438U568S33MANIFOLD PISTON, F10 ONLY
    2438U568S34PLATE F5 ONLY2438U568S35PLATE F6 & F10 ONLY
    2438U568S36SEAL2438U568R120SEAL KIT
    2438U568F1CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS2438U568F2BUCKET CYLINDER
    2438U568F3CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS2438U568F4CYLINDER, BUCKET ASSY, CONSISTS OF THE FOLLOWING PARTS
    2438U568S1TUBE2438U568S2BUSHING
    2438U568S3ROD2438U308S4PISTON
    R45P0049D3SEALR45P0051D5O-RING
    R45T0014D4WEAR RINGZD12G06000O-RING,59.40mm ID x 65.60mm OD x 3.10mm
    2438U568S9BACK-UP RING2438U308S44NUT
    2438U308S45LOCKING RING2438U308S12PLATE
    2438U568S13SPRING2438U568S14COVER
    2438U308S15BUSHING2438U308S16CLIP
    ZD12P12000O-RING2438U308S18BACK-UP RING
    2438U308S39O-RINGR45P0050D10SEAL
    45Z91D126O-RING2438U322S33PACKING
    2438U322S31PLATE F1 ONLY2438U552S24SEAL
    2438U568S25BUSHING2438U282S23SNAP RING
    ZS23C14055SCREW,Hex Socket Head, M14 x 55mm2445R138D6SEAL,70mm ID x 85.3mm OD x 4mm Thk
    2445R138D7SEAL,80mm ID x 95mm OD x 4mm Thk2438U568S32SPRING F3 & F4 ONLY
    2438U568S33MANIFOLD PISTON, F3 & F4 ONLY2438U568S34PLATE F3 ONLY
    2438U568S35PLATE F4 ONLY2438U568R100REPAIR KIT
    2438U568R110REPAIR KIT

    5. Related:


    All the picture is just for your reference.

    We can provide service according to the client's requirements!

    We always promise to offer excellent products as well as satisfactory service to our clients all over the world.

    If you have any problems with details please contact us, we can supply different pressure spare parts with different models as you like.


    Welcome to contact us, we can provide high quality and the best price!
