    708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit For Komatsu PC200-6H

    Ask Lasest Price
    Brand Name : HQPA/OEM
    Model Number : 708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit
    Certification : ISO9001
    Price : negotiation
    Payment Terms : Western Union, L/C, T/T, MoneyGram, D/A, D/P
    Supply Ability : 500 Sets per Week
    Delivery Time : 3-5 days after payment received(public holiday excluded)
    • Product Details
    • Company Profile

    708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit For Komatsu PC200-6H

    708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit for Komatsu PC200-6H
    1.Product Description:

    The hydraulic main pump is a kind of fluid pump. About the fluid sealing, it usually uses the mechanical seal to contain the fluid within a vessel (typically pumps, mixers, etc.) where a rotating shaft passes through a stationary housing or occasionally, where the housing rotates around the shaft.


    Mechanical seals are usually fixed at the point of entry or exit of a rotating shaft. Typically it is used to prevent the leakage of one high-pressure fluid into a lower pressure fluid.



    2.General Product Information:


    708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit for Komatsu PC200-6H
    Brand NameHQPA/OEM
    Product Name708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit for Komatsu PC200-6H
    Product styleHydraulic Main Pump Seal Kit / Main Pump Seal Kit
    Part No.708-2L-00411KT 708-2L-00460KT 708-2L-00461KT 708-2L-00412 708-2L-00411 708-2L-00460 708-2L-00461 7082L00412KT 7082L00411KT 7082L00460KT 7082L00461KT 7082L00412 7082L00411 7082L00460 7082L00461 Hydraulic Pump Assy
    Related parts:Boom Cylinder Seal Kit / Arm Cylinder Seal Kit / Swing Motor Seal Kit / Travel Motor Seal Kit / Main Pump Seal Kit / Pilot Pump Seal Kit / Regulator Valve Seal Kit / Main Control Valve Seal Kit
    ApplicationKomatsu PC200-6 PC200-6H PC200-6S PC200-6J PC200LC-6H PC200LC-6 PC200LC-6J PC200LC-6S PC210-6 PC210LC-6G PC210-6G PC210LC-6
    MOQ1 PC
    Condition100% New
    PackageInner-Plastic Bag; Outer -Standard Carton Box.
    PaymentWestern Union, L/C, T/T, MoneyGram, D/A, D/P etc.
    Departure portsHuangpu(Guangzhou), China (Mainland)
    Delivery time3-5 days after payment received(public holiday excluded)
    Place of originChina (Mainland)
    ApplicationExcavators, heavy machinery, mining, earth-moving, construction machinery, digger, car, truck.

    3. Fit Model


    Part Number: 708-2L-00411 708-2L-00460
    Group: Hydraulic Main Pump Seal Kit
    Fit for model: Komatsu PC200-6 PC200-6H PC200-6S PC200-6J PC200LC-6H PC200LC-6 PC200LC-6J PC200LC-6S PC210-6 PC210LC-6G PC210-6G PC210LC-6


    4.Related parts


    708-2L-00411 708-2L-00460 Hydraulic Main Pump Seal Kit for Komatsu PC200-6H


    Part NoParts namePart NoParts name
    708-2L-01442PUMP SUB ASS'Y708-2L-00460PUMP ASS'Y
    708-2L-00412PUMP ASS'Y708-2L-00411PUMP ASS'Y
    708-2L-01441PUMP SUB ASS'Y708-2L-01440PUMP SUB ASS'Y
    708-2L-04240CASE ASS'Y,FRONT07044-12412PLUG
    07002-62434O-RING708-1W-28910O-RING
    720-68-19870PLUG07002-61223O-RING
    708-2L-23940O-RING04530-11018BOLT,EYE
    04530-01018BOLT,EYE708-8E-16150PLUG
    07002-61023O-RING708-2L-23920O-RING
    708-8H-11530PLUG07002-61423O-RING
    708-2L-23950O-RING702-21-07010VALVE ASS'Y
    708-2L-04291BLOCK ASS'Y708-2L-04290BLOCK ASS'Y
    708-2L-23970O-RING07040-11007PLUG
    07002-61023O-RING708-2L-23920O-RING
    01252-60865BOLT203-60-62220BOLT
    21Y-62-17810ELBOW07235-10210ELBOW
    07002-61423O-RING708-2L-23950O-RING
    01582-11008NUT708-2L-29410HOSE
    708-2L-29420HOSE708-2L-29430HOSE
    708-2L-23960O-RING07000-B2011O-RING
    708-2L-29450ELBOW01583-51408NUT
    708-2L-29460ORIFICE708-2L-32260BEARING
    708-2L-22271RING,SNAP07000-A5165O-RING
    04020-01228PIN07000-B2010O-RING
    07000-B2012O-RING07000-B2014O-RING
    708-2L-25480FILTER01010-61450BOLT
    01643-31445WASHER708-2L-32110SHAFT,FRONT
    708-2L-32150BEARING708-2E-05040WASHER KIT
    708-25-12790RING,SNAP708-25-52861SEAL,OIL
    708-2L-22160SPACER04065-06825RING,SNAP
    708-2L-04141BLOCK ASS'Y,FRONT720-68-19610PIN
    04065-04818RING,SNAP708-2L-23131SEAT
    708-2L-33160SPRING708-7L-13140SEAT
    708-2L-23351GUIDE,RETAINER708-2L-23360PIN
    708-2L-33340RETAINER,SHOE708-2L-33310PISTON SUB ASS'Y
    708-2L-04361CRADLE ASS'Y,FRONT04020-01228PIN
    07000-B1009O-RING01252-61230BOLT
    708-2L-24514PISTON,SERVO708-2L-24670SEAL
    708-2L-24570SLIDER708-2L-24560STOPPER
    07000-B3040O-RING07001-03040RING,BACK-UP
    708-2L-24522COVER01252-61445BOLT
    113-43-31380WASHER708-2L-24640BOLT
    708-2L-24650NUT708-2L-24630SPRING
    708-2L-24531SCREW708-2L-24530SCREW
    04530-11222BOLT,EYE04530-01222BOLT,EYE
    20B-27-11210BLEEDER706-87-40150PLUG
    708-8E-16150PLUG07002-61023O-RING
    708-2L-23920O-RING708-8H-11530PLUG
    07002-61423O-RING708-2L-23950O-RING
    04020-01228PIN07000-B1009O-RING
    01252-61230BOLT708-2L-24514PISTON,SERVO
    708-2L-24670SEAL708-2L-24570SLIDER
    708-2L-24560STOPPER07000-B3040O-RING
    07001-03040RING,BACK-UP708-2L-24522COVER
    01252-61445BOLT113-43-31380WASHER
    708-2L-24640BOLT708-2L-24650NUT
    708-2L-24630SPRING708-2L-24531SCREW
    708-2L-24530SCREW07002-63634O-RING
    708-2L-24620O-RING708-2L-24661WASHER
    708-2L-24660WASHER708-2L-24590NUT

    5. Related models:


    PC200-6PC200-6HPC200-6SPC200-6JPC200LC-6H
    PC200LC-6PC200LC-6JPC200LC-6SPC210-6PC210LC-6G
    PC210-6GPC210LC-6PC390LL-10PC360-8M0PC360LC-11
    PC03-1PC03-2PC03-2-APC05-1PC05-5
    PC05-6PC05-7PC07-1PC07-2PC08UU-1
    PC08UU-1-APC09-1PC09-1-APC09-1-BPC09FR-1
    PC10-1PC10-2PC10-3PC10-5PC10-6
    PC10-7PC100-1PC100-3PC100-4PC100-5

    Welcome to contact us, we can provide high quality and the best price!
